High End 8CH 12MP 2592x1920P NVR With 3TB Hard Drive 5MP Camera IP System 42IR/
DescriptionHigh End 8CH 12MP 2592x1920P NVR With 3TB Hard Drive & (8) 5.0 MP 2.8-12mm Varifocal Camera System NVR FeatureQuad-core 8 CH NVR, Support Live View, Storage, and Playback up to 12.3MP IP Camera, 80MB Input Bandwidth, 8 Built-in PoE, 4K (3840x2160) HDMI, VGA, CVBS, 4 POS via TCP/IP, H.264/H.264 Zip+, H.265 ReadyQuad-core 8 Channel Network Video RecorderSupport Live View, Storage, and Playback up to 12.3MP IP Camera80MB Input Bandwidth8 Built-in PoE4K (3840x2160) HDMI, VGA, CVBS Video Output2 SATA up to 12TB HDD4 POS via TCP/IPSupport 6MP / 12.3MP FisheyeSupport H.264/H.264 Zip+, H.265 ReadyVideo/Audio InputIP Video Input8-CH, Up to 12MP ResolutionTwo-Way Audio Input1-CH, RCA (2.0 Vp-p, 1kΩ)NetworkIncoming Bandwidth80MbpsOutgoing Bandwidth256MbpsRemote Connection128Video/Audio OutputRecording Resolution12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIFHDMI Output4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 ×1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60HzVGA Output1-ch, resolution: 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60HzCVBS Output1-chAudio Output1-CH, RCA (Linear, 1kΩ)DecodingLive View/ Playback Resolution12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIFSynchronous Playback8-CHCapability2-ch 4K, or 8-ch 1080pHard DiskSATA2 SATA Interfaces for 2 HDDsCapacityUp to 8TB for Each DiskExternal InterfaceNetwork Interface1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfacesUSB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0Alarm In/Out4/1PoEInterface8 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaceMax. Power≤120WSupported StandardIEEE 802.3 af/atGeneralPower Supply100~240V ACConsumption≤15WWorking Temperature+14ºF ~ +131 ºF(-10ºC ~ +55ºC)Working Humidity10% - 90%Casing19-Inch Rack-Mounted 1U CasingDimension380 × 315× 52 mm (15" × 12.4" × 2.0")Weight≤8.8lb (4Kg) Bullet Camera Feature 5MP High Definition2592x1920P2.8-12mm Varifocal Lens42 IR LEDs up to 125ftONVIF SupportSupport OSD Menu 3D DNR, WDR, BLC, VCA IP66 DC 12V, PoE Camera SVN730W Image Sensor1/3" SONY CMOS chipsetMin. Illumination0.001Lux (F1.2,AGC ON), 0 Lux with IRLens2.8 - 12 mm Varifocal LensLens MountΦ14Day & NightIR cut filter with auto switchVideo CompressionH.264 / MJPEG/H.265H.264 TypeH.264, Baseline/Main Profile/High Profile codeVideo Bit Rate32 Kbps ~ 16 Mbps，CBR/VBRProtocolsUDP, RTP, RTSP, TRCP, DNS, DDNS, DHCP, FTP,NTP,PPPOE,SMTP,UPNPWorking Temperature /Humidity -22 °F ~ 140°F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) Power SupplyDC12V /1A/PoEIR Range42IR LEDs Approx. 125ftWeather Proof RatingsIP66Dimensions3.7” × 4.1” × 10.2”(95×105×258.6 mm)Weight2lbs Dome Camera Feature5MP High Definition1/3” Sony CMOS2592 x 1920P2.8mm -12mm Varifocal Lens with IR Cut30 IR LEDs up to 110ftSupport ONVIFSupport OSD Menu3D DNR, WDR, BLC, VCA, 3-AxisVandalproof, IP66DC 12V, PoECamera SVN288Image Sensor1/3" Sony COMSMin. Illumination0.001Lux (F1.2,AGC ON), 0 Lux with IRLens2.8 - 12 mm VarifocalLens MountΦ14Day & NightIR cut filter with auto switchDNR3D DNRWide Dynamic RangeDWDRVideo CompressionH.264 / MJPEG/ H.264H / H.264BH.264 TypeH.264, Baseline/Main Profile/High Profile codeVideo Bit Rate32 Kbps ~ 16 Mbps，CBR/VBRProtocolsUDP, RTP, RTSP, TRCP, DNS, DDNS, DHCP, FTP,NTP,PPPOE,SMTP,UPNPWorking Temperature /Humidity -22 °F ~ 140°F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) Power SupplyDC12V ± 10%, PoE (802.3af)Power ConsumptionMax. 5.5W (Max. 7.5 W with IR cut filter on)IR Range110 feetWeather Proof RatingsIP66DimensionsΦ 5.5" x 3.9" (Φ 140 x 99.9mm)Weight2.4lbs Package includesSVLTN8608-8P HD 8Channel 12MP IP NVR 3TB CCTV hard drive6 x SVN730W- 2592x1920P Manual Bullet Varefocal Zoom IP POE Security Camera2 x SVN288 – 5MP Dome Varefocal Zoom IP POE Security CameraPower Supply for NVRCD with user manual and softwarePower Cable No Include ( single network cable directly connects each IP camera to the NVR supplying both power and a video signal. This time no extra power cable needed just plug one Ethernet cable for one camera and its on the go.) One Year warranty
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | Amview |
| MPN | Does Not Apply |
| Model | SVN268 SVN730W |
| Camera Connectivity | IP/Network - Wired |
| Camera Type | Bullet & Dome |
| Type | Camera System |
DescriptionHigh End 8CH 12MP 2592x1920P NVR With 3TB Hard Drive & (8) 5.0 MP 2.8-12mm Varifocal Camera System NVR FeatureQuad-core 8 CH NVR, Support Live View, Storage, and Playback up to 12.3MP IP Camera, 80MB Input Bandwidth, 8 Built-in PoE, 4K (3840×2160) HDMI, VGA, CVBS, 4 POS via TCP/IP, H.264/H.264 Zip+, H.265 ReadyQuad-core 8 Channel Network Video RecorderSupport Live View, Storage, and Playback up to 12.3MP IP Camera80MB Input Bandwidth8 Built-in PoE4K (3840×2160) HDMI, VGA, CVBS Video Output2 SATA up to 12TB HDD4 POS via TCP/IPSupport 6MP / 12.3MP FisheyeSupport H.264/H.264 Zip+, H.265 ReadyVideo/Audio InputIP Video Input8-CH, Up to 12MP ResolutionTwo-Way Audio Input1-CH, RCA (2.0 Vp-p, 1kΩ)NetworkIncoming Bandwidth80MbpsOutgoing Bandwidth256MbpsRemote Connection128Video/Audio OutputRecording Resolution12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIFHDMI Output4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 ×1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60HzVGA Output1-ch, resolution: 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60HzCVBS Output1-chAudio Output1-CH, RCA (Linear, 1kΩ)DecodingLive View/ Playback Resolution12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIFSynchronous Playback8-CHCapability2-ch 4K, or 8-ch 1080pHard DiskSATA2 SATA Interfaces for 2 HDDsCapacityUp to 8TB for Each DiskExternal InterfaceNetwork Interface1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfacesUSB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0Alarm In/Out4/1PoEInterface8 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaceMax. Power≤120WSupported StandardIEEE 802.3 af/atGeneralPower Supply100~240V ACConsumption≤15WWorking Temperature+14ºF ~ +131 ºF(-10ºC ~ +55ºC)Working Humidity10% – 90%Casing19-Inch Rack-Mounted 1U CasingDimension380 × 315× 52 mm (15″ × 12.4″ × 2.0″)Weight≤8.8lb (4Kg) Bullet Camera Feature 5MP High Definition2592x1920P2.8-12mm Varifocal Lens42 IR LEDs up to 125ftONVIF SupportSupport OSD Menu 3D DNR, WDR, BLC, VCA IP66 DC 12V, PoE Camera SVN730W Image Sensor1/3″ SONY CMOS chipsetMin. Illumination0.001Lux (F1.2,AGC ON), 0 Lux with IRLens2.8 – 12 mm Varifocal LensLens MountΦ14Day & NightIR cut filter with auto switchVideo CompressionH.264 / MJPEG/H.265H.264 TypeH.264, Baseline/Main Profile/High Profile codeVideo Bit Rate32 Kbps ~ 16 Mbps，CBR/VBRProtocolsUDP, RTP, RTSP, TRCP, DNS, DDNS, DHCP, FTP,NTP,PPPOE,SMTP,UPNPWorking Temperature /Humidity -22 °F ~ 140°F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) Power SupplyDC12V /1A/PoEIR Range42IR LEDs Approx. 125ftWeather Proof RatingsIP66Dimensions3.7” × 4.1” × 10.2”(95×105×258.6 mm)Weight2lbs Dome Camera Feature5MP High Definition1/3” Sony CMOS2592 x 1920P2.8mm -12mm Varifocal Lens with IR Cut30 IR LEDs up to 110ftSupport ONVIFSupport OSD Menu3D DNR, WDR, BLC, VCA, 3-AxisVandalproof, IP66DC 12V, PoECamera SVN288Image Sensor1/3″ Sony COMSMin. Illumination0.001Lux (F1.2,AGC ON), 0 Lux with IRLens2.8 – 12 mm VarifocalLens MountΦ14Day & NightIR cut filter with auto switchDNR3D DNRWide Dynamic RangeDWDRVideo CompressionH.264 / MJPEG/ H.264H / H.264BH.264 TypeH.264, Baseline/Main Profile/High Profile codeVideo Bit Rate32 Kbps ~ 16 Mbps，CBR/VBRProtocolsUDP, RTP, RTSP, TRCP, DNS, DDNS, DHCP, FTP,NTP,PPPOE,SMTP,UPNPWorking Temperature /Humidity -22 °F ~ 140°F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) Power SupplyDC12V ± 10%, PoE (802.3af)Power ConsumptionMax. 5.5W (Max. 7.5 W with IR cut filter on)IR Range110 feetWeather Proof RatingsIP66DimensionsΦ 5.5″ x 3.9″ (Φ 140 x 99.9mm)Weight2.4lbs Package includesSVLTN8608-8P HD 8Channel 12MP IP NVR 3TB CCTV hard drive6 x SVN730W- 2592x1920P Manual Bullet Varefocal Zoom IP POE Security Camera2 x SVN288 – 5MP Dome Varefocal Zoom IP POE Security CameraPower Supply for NVRCD with user manual and softwarePower Cable No Include ( single network cable directly connects each IP camera to the NVR supplying both power and a video signal. This time no extra power cable needed just plug one Ethernet cable for one camera and its on the go.) One Year warranty
