8CH IPC H.265 NVR 2592x1920P 5MP PoE 48IR IP ONVIF Security Camear BLC O)) WDR
Description High Defintion 8CH 12MP 2592x1920P NVR 2TB HDD + (8) 5.0 MP 2.8-12mm Varifocal Camera System NVR Feature Quad-core 8 CH NVR, Support Live View, Storage, and Playback up to 12.3MP IP Camera, 80MB Input Bandwidth, 8 Built-in PoE, 4K (3840x2160) HDMI, VGA, CVBS, 4 POS via TCP/IP, H.264/H.264 Zip+, H.265 Ready Quad-core 8 Channel Network Video Recorder Support Live View, Storage, and Playback up to 12.3MP IP Camera 80MB Input Bandwidth 8 Built-in PoE 4K (3840x2160) HDMI, VGA, CVBS Video Output 2 SATA up to 12TB HDD 4 POS via TCP/IP Support 6MP / 12.3MP Fisheye Support H.264/H.264 Zip+, H.265 Ready NVR system Specfication Video/Audio Input IP Video Input 8-CH, Up to 12MP Resolution Two-Way Audio Input 1-CH, RCA (2.0 Vp-p, 1kΩ) Network Incoming Bandwidth 80Mbps Outgoing Bandwidth 256Mbps Remote Connection 128 Video/Audio Output Recording Resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF HDMI Output 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 ×1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz VGA Output 1-ch, resolution: 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz CVBS Output 1-ch Audio Output 1-CH, RCA (Linear, 1kΩ) Decoding Live View/ Playback Resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Synchronous Playback 8-CH Capability 2-ch @ 4K, or 8-ch @1080p Hard Disk SATA 2 SATA Interfaces for 2 HDDs Capacity Up to 8TB for Each Disk External Interface Network Interface 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces USB Interface Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 Alarm In/Out 4/1 PoE Interface 8 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface Max. Power ≤120W Supported Standard IEEE 802.3 af/at General Power Supply 100~240V AC Consumption ≤15W Working Temperature +14ºF ~ +131 ºF(-10ºC ~ +55ºC) Working Humidity 10% - 90% Casing 19-Inch Rack-Mounted 1U Casing Dimension 380 × 315× 52 mm (15" × 12.4" × 2.0") Weight ≤8.8lb (4Kg) Camera Feature 5MP High Definition HD 2592x1920P 3.6mm Lens Wide Angle Viewing with IR Cut 48IR LEDs up to 130ft Support Onvif Support OSD Menu 3D DNR, WDR, BLC, VCA IP66 DC 12V, PoE Camera SVN383W Image Sensor SONY CMOS CCD Min. Illumination 0.001Lux @(F1.2,AGC ON), 0 Lux with IR Lens 3.6 mm Wide Angle Viewing Lens Mount ?14 Day & Night IR cut filter with auto switch DNR 3D DNR Wide Dynamic Range DWDR Video Compression H.264 / MJPEG/ H.264H / H.264B H.264 Type H.264, Baseline/Main Profile/High Profile code Video Bit Rate 32 Kbps ~ 16 Mbps?CBR/VBR Protocols UDP, RTP, RTSP, TRCP, DNS, DDNS, DHCP, FTP,NTP,PPPOE,SMTP,UPNP Working Temperature /Humidity -22 °F ~ 140°F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) Power Supply DC12V ± 10%, PoE (802.3af) Power Consumption Max. 5.5W (Max. 7.5 W with IR cut filter on) IR Range 130 feet Weather Proof Ratings IP66 Dimensions ? 5.5" x 3.9" (? 140 x 99.9mm) Weight 0.75KG Package includes SVL8608D-P8 HD 12MP 8Channel H.265 NVR 2TB CCTV hard drive 8x SVN383W – 2592x1920P Dome IP POE Security Camera Power Supply for NVR CD with user manual and software Power Cable No Include ( single network cable directly connects each IP camera to the NVR supplying both power and a video signal. This time no extra power cable needed just plug one Ethernet cable for one camera and its on the go.) One Year warranty
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | Amview |
| MPN | Does Not Apply |
| Camera Connectivity | IP/Network - Wired |
| Camera Type | Dome |
| Connectivity | Wired |
| Application | Indoor/Outdoor |
| Features | Audio Recording |
| Type | Camera System |
Description High Defintion 8CH 12MP 2592x1920P NVR 2TB HDD + (8) 5.0 MP 2.8-12mm Varifocal Camera System NVR Feature Quad-core 8 CH NVR, Support Live View, Storage, and Playback up to 12.3MP IP Camera, 80MB Input Bandwidth, 8 Built-in PoE, 4K (3840×2160) HDMI, VGA, CVBS, 4 POS via TCP/IP, H.264/H.264 Zip+, H.265 Ready Quad-core 8 Channel Network Video Recorder Support Live View, Storage, and Playback up to 12.3MP IP Camera 80MB Input Bandwidth 8 Built-in PoE 4K (3840×2160) HDMI, VGA, CVBS Video Output 2 SATA up to 12TB HDD 4 POS via TCP/IP Support 6MP / 12.3MP Fisheye Support H.264/H.264 Zip+, H.265 Ready NVR system Specfication Video/Audio Input IP Video Input 8-CH, Up to 12MP Resolution Two-Way Audio Input 1-CH, RCA (2.0 Vp-p, 1kΩ) Network Incoming Bandwidth 80Mbps Outgoing Bandwidth 256Mbps Remote Connection 128 Video/Audio Output Recording Resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF HDMI Output 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 ×1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz VGA Output 1-ch, resolution: 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz CVBS Output 1-ch Audio Output 1-CH, RCA (Linear, 1kΩ) Decoding Live View/ Playback Resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Synchronous Playback 8-CH Capability 2-ch @ 4K, or 8-ch @1080p Hard Disk SATA 2 SATA Interfaces for 2 HDDs Capacity Up to 8TB for Each Disk External Interface Network Interface 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces USB Interface Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 Alarm In/Out 4/1 PoE Interface 8 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface Max. Power ≤120W Supported Standard IEEE 802.3 af/at General Power Supply 100~240V AC Consumption ≤15W Working Temperature +14ºF ~ +131 ºF(-10ºC ~ +55ºC) Working Humidity 10% – 90% Casing 19-Inch Rack-Mounted 1U Casing Dimension 380 × 315× 52 mm (15″ × 12.4″ × 2.0″) Weight ≤8.8lb (4Kg) Camera Feature 5MP High Definition HD 2592x1920P 3.6mm Lens Wide Angle Viewing with IR Cut 48IR LEDs up to 130ft Support Onvif Support OSD Menu 3D DNR, WDR, BLC, VCA IP66 DC 12V, PoE Camera SVN383W Image Sensor SONY CMOS CCD Min. Illumination 0.001Lux @(F1.2,AGC ON), 0 Lux with IR Lens 3.6 mm Wide Angle Viewing Lens Mount ?14 Day & Night IR cut filter with auto switch DNR 3D DNR Wide Dynamic Range DWDR Video Compression H.264 / MJPEG/ H.264H / H.264B H.264 Type H.264, Baseline/Main Profile/High Profile code Video Bit Rate 32 Kbps ~ 16 Mbps?CBR/VBR Protocols UDP, RTP, RTSP, TRCP, DNS, DDNS, DHCP, FTP,NTP,PPPOE,SMTP,UPNP Working Temperature /Humidity -22 °F ~ 140°F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) Power Supply DC12V ± 10%, PoE (802.3af) Power Consumption Max. 5.5W (Max. 7.5 W with IR cut filter on) IR Range 130 feet Weather Proof Ratings IP66 Dimensions ? 5.5″ x 3.9″ (? 140 x 99.9mm) Weight 0.75KG Package includes SVL8608D-P8 HD 12MP 8Channel H.265 NVR 2TB CCTV hard drive 8x SVN383W – 2592x1920P Dome IP POE Security Camera Power Supply for NVR CD with user manual and software Power Cable No Include ( single network cable directly connects each IP camera to the NVR supplying both power and a video signal. This time no extra power cable needed just plug one Ethernet cable for one camera and its on the go.) One Year warranty
